Merits Pioneer 10 Mobility Scooter - Up to 500 lbs

69.00
        SPECIAL OFFER

          Please select all product options

          Product was out of stock

          share
          Description

          Merits Pioneer 10 mobility scooter was designed with your safety in mind. It's durable heavy duty frame and 4-wheel design can support users up to 500 pounds with a rear suspension system for a comfortable and smooth ride.

          FEATURES

          • Rear Suspension
          • 500 lbs weight capacity
          • Hydraulic, adjustable tiller
          • Swivel seat
          • 22”W x 20”D x 22”H, sliding, captain seat
          • Half-speed inhibit switch for safety speed control
          • Headlights, tail lights, turn signals and hazard lights
          • Automatic sensors to reduce steep on sharp turns
          • 4” ground clearance

          KEY SPECS

          • Drive Range: 32
          • Max Speed: 7.50 mph
          • Heaviest Piece: 121 lbs.
          • Weight capacity: 500 lbs.
          • Weight: 290 lbs.

          Its strong, heavy-duty one-piece frame makes it a suitable mobility scooter for outdoor use and uneven terrain for users who weigh less than 500 lbs.

          Merits Pioneer 10 is an ideal mobility scooter for users who weigh less than 500 pounds and for the outdoors use and navigating through uneven terrain.

          Specifications

          View the specs of the Merits Pioneer 10 Mobility Scooter (Model No. S341) below:

          Max Speed: 7.50 mph
          Scooter Disassembles: No
          Scooter Drive Range: 32.00 miles
          Heaviest Piece: 121 lbs.
          Suspension: Yes
          Scooter Seat Width: 22"
          Delta Tiller: No
          Weight Capacity: 500 lbs
          Turning Radius: 62"
          Ground Clearance: 4.00"
          Max Incline Rating: 12 °
          Seat Depth: 20
          Back Height: 22"
          Max Seat to Ground Height: 25"
          Lowest Seat to Ground Height: 22"
          Max Seat to Deck Height: 19"
          Multiple Seating Options: No
          Height Adjustable Seat: Yes
          High-Back Seat: Yes
          Armrest Options: Flip-Back
          Height Adjustable
          Width Adjustable
          Flip-Back Armrests: Yes
          Wheel Type: Four Wheeled
          Front Wheel Size: 12"
          Rear Wheel Size: 12"
          Air-Filled (Pneumatic) Tires: Yes
          Overall Width: 27"
          Overall Length: 54"
          Axle-to-Axle Length: 45.00"
          Collapsible: No
          Foldable: No
          Battery Type: 12-Volt, Group 24
          Batteries Included: Yes
          Battery Charger Type: Off Board
          Larger Battery Option: No
          Motor Size: DC 24V, 400W
          Braking System: Intelligent, regenerative electromagnetic brakes
          Basket Included: Yes
          Headlight: Yes
          Extended Base: No
          Weight Without Batteries: 235.00 lbs.
          Battery Pack Weight: 55.00 lbs.
          Seat Section Weight: 60.00 lbs.
          Base and Tiller Weight: 121.00 lbs.


          Owner's Manual:

          WHAT'S INSIDE THE BOX

          Here is what's included:

          • 1 x Merits Pioneer 10 Mobility Scooter
          • 2 x 12V, Group AH Batteries (Standard)
          • 1 x seat
          • 1 x headrest
          • 2 x armrests
          • 1 x key
          • 1 x charger
          • 1 x power cord
          • 2 x turn signals
          • 2 x anti-tip wheels
          • 2 x bumpers
          • 1 x headlight
          • 1 x front basket
          • Owner's Manual

          WARRANTY

          • 5 year warranty on Frame
          • 18 month warranty on Electronics
          • 18 month warranty on Motor
          • 12 month warranty on Batteries



          Authorized Dealer
